Combustion Optimisation

INERCO has a wide range of proprietary technologies for the global optimisation of combustion process in industrial boilers and furnaces (improvement of efficiency, reduction of pollutant emissions, correction of operational constraints, etc.).
Among the results obtained by applying INERCO's combustion optimisation technologies in thermal units, it can be remarked the achievement of heat rate improvements between 0.5% and 1.5%, along with simultaneous reductions in NOX emissions in the range of 15%-40%.
Closed-loop Combustion Control (ABACO)

Closed-loop Combustion Control (ABACO)

In-furnace Gas Monitoring (ABACO-Opticom)

In-furnace Gas Monitoring (ABACO-Opticom)

Carbon-in-ash Control (ABACO-LOI)

Carbon-in-ash Control (ABACO-LOI)

Balancing of Coal Supply to Burners (ABACO-Coal)

Balancing of Coal Supply to Burners (ABACO-Coal)

Control of Coal Flow Rate and Particle Size Distribution (ABACO-PCSampler)

Control of Coal Flow Rate and Particle Size Distribution (ABACO-PCSampler)

Gas Monitoring in Rotary Kilns (ABACO-Pirocom)

Gas Monitoring in Rotary Kilns (ABACO-Pirocom)

Closed-loop Combustion Control (ABACO)

Global combustion process optimisation in industrial boilers and furnaces:

o Combustion process balancing.

o Efficiency improvement.

o Carbon-in-ash minimisation.

o Reduction of environmental emissions (NOx, CO2, CO, SOx, particulates, etc.).

o Use of new fuel blends.

o Limitation of operational problems (slagging, fouling, corrosion).

Integration of advanced technologies for closed-loop control of local combustion conditions:

o Combustion monitoring systems.

o New regulation elements.

o Advanced combustion control based on Expert Systems.

MAIN RESULTS

Improvements in thermal unit heat rate (0.5%-1.5%).

Simultaneous NOx reductions in the range of 15%-40%

Control on operational issues (carbon-in-ash, CO production).

Efficient use of lower quality or lower priced fuels.

In-furnace Gas Monitoring (ABACO-Opticom)

Combustion optimisation system based on the accurate monitoring of the combustion process.

Automatic measurement and control of in-furnace local gas concentrations in industrial boilers and furnaces (O2, CO, NOx, CO2, SO2).

Identification of key settings and parameters to optimise emissions and heat transfer through combustion tuning (distribution of fuel and air, excess O2, etc.).

Prevention of detrimental operating conditions in boiler walls.

MAIN RESULTS

Actual results based on information taken directly from selected in-furnace points.

Actual concentration profiles (no averaged values, no interpolation software).

Simultaneous improvement in heat range in a range of 0.5%-1.0%.

Typical NOx emissions reduction in a range of 15%-30%, exclusively through combustion tuning.

Improvements in carbon-in-ash and CO emissions.

Corrosion and slagging control.

Carbon-in-ash Control (ABACO-LOI)

Technology for the automated sampling of fly-ash and the on-line measurement of carbon-in-ash based on Loss On Ignition (LOI) determination.

Reproduction of reference laboratory techniques used for the measurement of unburned matter in the fly-ash generated in thermal combustion units.

Additional application for the on-line characterisation of parameters such as volatile matter or total moisture in pulverised coal sample.

BENEFITS OF USING ABACO-LOI

Assured and proven reliability.

Unique monitor in the current market in which the measurement methodology is the reference technique used in the laboratory.

High precision.

No drift in the measurements or need of calibration.

Unaffected by variations in the physical-chemical properties of coal or fly ash properties.

Unaffected by interfering elements: hydroxides, carbonates, ammonium compounds, etc.

Cost-effective solution involving different samplers with a single analyser (multiplexing).

No obstructions during fly–ash transport.

Balancing of Coal Supply to Burners (ABACO-Coal)

Advanced wear resistant dampers for tuning coal flow rates to burners.

Regulating damper conceived and designed for high durability, maximum reliability and safe process operation.

MAIN ADVANTAGES

Typical imbalance reductions from values higher than ±30% to levels below ±5%.

High regulation capability, typically ±30% of nominal flow rate.

Easy automation from Control Room.

Wear and abrasion resistance guaranteed through the use of anti-wear materials.

Intrinsically safe design with mechanical protections to avoid duct section blockages.

Design based and validated by fluid dynamics simulations.

Easy maintenance and component replacement.

Optional verification of ATEX Directive, if required.

Control of Coal Flow Rate and Particle Size Distribution (ABACO-PCSampler)

Control of Coal Flow Rate and Particle Size Distribution (ABACO-PCSampler).

Optional homogenisation of pulverised solid samples.

Representative characterisation of pulverised coal from ducts to burners.

Rotary isokinetic sampling of pulverised coal according to ISO 9931 Standard.

Enables the tuning of imbalances found in the coal supplied to each individual burner.

KEY FEATURES

Just one non-specialised operator needed to obtain an accurate measurement.

Monitoring of the probe movement.

Automatic adjustment of isokinetic conditions.

Control over sampling time.

Adaptability to duct conditions.

High repeatability and reliability of measurements.

Assistance software for sampling.

Minimal training required for operation.

Gas Monitoring in Rotary Kilns (ABACO-Pirocom)

Direct and continuous characterisation of flue gases (O2, NOx, CO, CO2, SO2) at the exit of rotary kilns, such as those found in cement factories.

MAIN ADVANTAGES

Optimised design to avoid obstructions in the sampling line, even for maximum dust concentrations in flue gases.

Direct determination of actual excess O2 in kilns without possible air in-leakage via the rotating seal.

Control of the main operating variables (cooling flow rates, temperatures, etc.) towards highest availability and system protection.

Easy, low-cost and effortless replacement of spare parts.

Minimal maintenance by non-specialised operators.

Synergy with an optimised operation of non-catalytic NOx abatement systems.

RESULTS

Minimisation of operational excess O2. Typical reductions: 1%-3%.

Typical savings in furnace primary fuel: 8%-10%.

Typical NOxreductions: 35%-45%.

Process control for stable combustion conditions.

Reduction of ammonia reagent consumption (SNCR): 20%-30%.
